Cervelo Caledonia 105

Cervelo Caledonia 105
  • Color: Metallic Black
  • Color: Glacier
  • Color: Plum
$2,720.00 - $3,200.00
$3,200.00
Color:
Size: Select size
Please select options Unavailable

Details

Caledonia doesn't fit in a box nicely, and we like it that way. It was conceived on our Thursday night rides-routes that often play fast and loose with 'road ride.' Modern road riders are looking for bikes to handle long-distance, high pace, no limits, and offer maximum fun - the Caledonia delivers performance, comfort, and speed. Oh, and you can fit a 34mm tire in there. Or 31mm with fenders.

- Removable FDM
Our bolt-on front derailleur mount is made from high-strength aluminum alloy and attaches to the frame with two countersunk screws. This allows for easy replacement in the event of damage but also enables you to adapt to new standards as they become available or remove the front derailleur mount completely if you choose a 1x system.

- Integrated Accessory Mounts
Integrated mounts enable the use of fenders, lights, and computers without compromising the aerodynamics or structure of your bike. The built-in mount systems provide a simple and clean-looking solution.

Sizes:
Frame Size485154565861
Reach | mm 360 369 378 387 396 405
Stack | mm 505 530 555 580 605 630
Head Tube Angle 70.5° 71.5° 72° 72° 72° 72°
Front Center | mm 579.4 581.7 591.5 608.5 626 643
Bottom Bracket Drop | mm 76.5 76.5 74 74 71.5 71.5
Head Tube Length | mm 89.5 109.9 136 162.3 191.2 217.5
Top Tube Length | mm 502 522 543 565 581 598
Seat Tube Angle 74.5° 74° 73.5° 73° 73° 73°
Standover Height | mm 701 741 773 796 823 847
Trail | mm 60 60 60 60 60 60
Wheel Size 700C 700C 700C 700C 700C 700C
Fork Offset | mm 59 53 50 50 50 50
Wheelbase | mm 982.2 984.5 995.2 1012.3 1030.7 1047.8
Chainstay Length | mm 415 415 415 415 415 415
Sizes:
Frame SizeRider Height (cm)Rider Height (in)
48 150 - 160 4'11" - 5'3"
51 160 - 168 5'3" - 5'5"
54 168 - 176 5'5" - 5'7"
56 176 - 184 5'7" - 5'11"
58 184 - 192 5'11" - 6'4"
61 192 - 200 6'5" - 6'7"

Specs

Fork Cervélo All-Carbon, Tapered Caledonia Fork
Wheels Alexrims Boondocks 5, 12x142mm, 24H, 21mm IW, HG freehub, 6 bolt, tubeless compatible
Alexrims Boondocks 5, 12x100mm, 24H, 21mm IW, 6 bolt, tubeless compatible
Axles Cervelo Aero Thru-Axles, 12x100/142
Tires Zaffiro Pro V G2.0 700x30c
Bottom Bracket FSA, BBright thread together, 24mm spindle
Crankset Shimano FC-RS520, 50/34T, 12 Speed
Shifters Shimano 105, R7120, 12 speed
Front Derailleur Shimano 105, R7100, 12 speed
Rear Derailleur Shimano 105, R7100, 12 speed
Cassette/Freewheel Shimano 105, 11-34, 12 Speed
Chain Shimano M7100, 12 speed
Brakes Shimano 105
Rotors Shimano RT66 6-Bolt
Handlebars Cervélo Alloy, 31.8mm clamp
Stem Cervélo ST27 Alloy
Headset FSA IS2 1-1/8 x 1-1/2
Seatpost Cervélo Alloy 27.2 15mm Offset
Pedals Sold Separately
Saddle Cervélo Saddle

* Subject to change without notice.

Part Numbers

Option UPC MPN Store SKU
Glacier / 48cm 042677621898 0I0CAA112A48
Glacier / 51cm 042677621904 0I0CAA112A51
Glacier / 54cm 042677621911 0I0CAA112A54
Glacier / 56cm 042677621928 0I0CAA112A56
Glacier / 58cm 042677621935 0I0CAA112A58
Glacier / 61cm 042677621942 0I0CAA112A61
Metallic Black / 48cm 042677621836 0I0CAA111A48
Metallic Black / 51cm 042677621843 0I0CAA111A51
Metallic Black / 54cm 042677621850 0I0CAA111A54 210000008158
Metallic Black / 56cm 042677621867 0I0CAA111A56
Metallic Black / 58cm 042677621874 0I0CAA111A58
Metallic Black / 61cm 042677621881 0I0CAA111A61
Plum / 48cm 042677621959 0I0CAA113A48
Plum / 51cm 042677621966 0I0CAA113A51
Plum / 54cm 042677621973 0I0CAA113A54
Plum / 56cm 042677621980 0I0CAA113A56
Plum / 58cm 042677621997 0I0CAA113A58
Plum / 61cm 042677622000 0I0CAA113A61
